The boom, bucket, and main frame are constructed from thickened Q355 wear-resistant manganese steel. Precision robot welding ensures exceptional torsion resistance and durability, making it perfectly suited for abrasive conditions such as sand, gravel, and ore mining.
FD10
FD10
Operating Load (Kg): 1000KG
Whole Machine Weight (Kg): 2200KG
Bucket Capacity (m³): 0.3M³
Unloading height (mm): 2400MM
Overall dimensions (mm): 4650*1500*2500(MM)
Product Description
Reliability
The boom, bucket, and main frame are constructed from thickened Q355 wear-resistant manganese steel. Precision robot welding ensures exceptional torsion resistance and durability, making it perfectly suited for abrasive conditions such as sand, gravel, and ore mining.
Advanced Powertrain
Powered by a premium "Golden Combination" powertrain, this loader delivers robust and smooth performance. It provides continuous power output without stalling during heavy-duty loading of sand, gravel, or soil. Backed by mature technology, it features affordable and easily accessible spare parts, significantly reducing long-term maintenance costs.
High Efficiency
The integrated design drastically minimizes power loss during transmission. The dual-speed system ensures "high torque for heavy-duty digging and fast travel for quick relocation," perfectly balancing the traction needed for heavy loading with high mobility around the site.
Working Device & Maintenance
Designed for ease of use and maintenance, it features articulated steering for a tight turning radius. With highly universal components and simplified maintenance routines, spare parts are easy to source and replace.
Key Selling Points
- Classic 490 Series Engine: Features a large displacement and a 90mm cylinder bore, providing superior torque reserves and explosive power for demanding tasks.
- Kingdun Torque Converter: Equipped with a premium "Kingdun" integrated torque converter for highly efficient power transmission and dual-speed gear matching.
- Heavy-Duty Chassis: Features a Model 130 wheel-side reduction drive axle. This heavy-duty chassis is built to withstand harsh conditions and offers exceptional load-bearing capacity.
- Premium Domestic Tires: Offers a larger footprint and stronger grip to prevent slipping on muddy or gravelly terrain. The thickened tread is highly puncture- and wear-resistant, reducing the risk of blowouts and lowering tire replacement costs.
- 2.4m Dump Height: Perfectly matches the unloading requirements of most agricultural tricycles, medium-sized dump trucks, and hoppers on the market. Whether for clearing manure in farms, transferring materials in breeding facilities, or transporting sand and gravel at small-to-medium construction sites, it handles it all effortlessly. A true multi-purpose machine!
